Protempis (Formerly Trimble) Bullet Comparison Chart

Protempis’s Bullet and Bullet 360 series of antennas are hardened with advanced technology filtering capabilities to provide reliable performance in hostile RF jamming environments. The Bullet series of antennas offer customers the flexibility and choices of constellations and configurations, and unmatched reliability.

Announcement of the end of life of some Bullet GPS Antennas



The following Bullet part numbers also have been discontinued: 57860-20, 57861-20, 97860-00, 97861-00, 101155-00, 101155-20, 101255-00, 101255-20. The recommended replacement is the Bullet 360 with TNC connector, part number 101898-00.

The following Bullet part numbers have been discontinued: 57860-30, 97860-10, 101155-10, 101255-10. The recommended replacement is Bullet 360 with F connector, part # 101898-10.

Due to diminishing sales, the following 2 Bullets have been discontinued with no replacement: 101355-10, 101355-20.

The updated line of Protempis GPS Antennas (formerly Trimble GPS Antennas) is reflected in the chart below.

Bullet L1 L2 Antenna Bullet 360 Antenna Bullet 720 Antenna
Designed For Dual Frequency – GPS L1 and L2 bands Designed specifically for the congested urban environments Rugged antenna built for harsh environments
Waterproof Housing ✅ ✅ ✅
RoHS II Compliant ✅ ✅ ✅
Extended temperature range (-40°C / +90°C) ✅ ✅ ✅
Multi-Constellation ✖️ ✅

GPS L1 & L5, Galileo E1 & E5, Beidou B1 & B2C, GLONASS G1 & IRNSS

 ✖️
Well suited for congested urban areas ✖️ ✅ ✅
Frequency Notes Dual Band
L1 & L2		 Single Band
L1		 Dual Band
L1 & L5
Item Numbers 94860-00
94859-00		 101155-00
101155-10
101155-20		 12851
