Poynting EPNT-1 | Cross-Polarised, Omni-Directional 5G/LTE & Wi-Fi CPE Antenna
Poynting EPNT-1 | Cross-Polarised, Omni-Directional 5G/LTE & Wi-Fi CPE Antenna - Poynting Antennas is backordered and will ship as soon as it is back in stock.
Click here to inquire about pricing or to become an authorized reseller of this product.
Poynting Antennas introduces the ePoynt series, an innovative antenna enclosure range designed to transform your LTE/5G router into high-performance Customer Premises Equipment (CPE). The EPNT-1 enclosure supports routers up to 185 x 145 x 45 mm³, delivering enhanced signal stability and throughput.
Seamless Router Integration: Designed to accommodate various LTE/5G router modules for easy plug-and-play setup. Wideband 4x4 MIMO Antennas: Covers 617–4200 MHz, ensuring strong LTE & 5G connectivity with up to 3.8 dBi peak gain.
Omni-Directional Wi-Fi Support: Built-in dual-band Wi-Fi antennas (2.4 GHz & 5–7.2 GHz) for reliable 2x2 MIMO performance. Optimised for Urban Deployments: Cross-polarised antennas enhance signal stability in built-up areas with multiple base stations.
Rugged & Weatherproof Design: IP65-rated enclosure ensures durability in harsh outdoor conditions. The EPNT-1 is the ideal solution for LTE & 5G deployments, providing a powerful, all-in-one antenna and enclosure for enhanced connectivity.
Key Features
- An all-in-one solution that integrates high-performance antennas with your router into a single, rugged outdoor enclosure, simplifying installation
- Minimal RF cable losses, as there is no need for lengthy RF cables to connect to your router, enhancing overall antenna performance
- Wideband 4x4 MIMO 4G/5G antennas
- 2x2 MIMO dual-band 2.4 GHz and 5 – 7.2 GHz Wi-Fi antennas
- Cross-polarised antennas for improved performance
- IP65 weather/dust and vandal-resistant enclosure
Ideal Applications
- Outdoor antenna for Fixed Wireless Access (FWA)
- Consumer 5G/LTE internet connectivity
- Industrial
- commercial 5G/LTE deployment
- Urban
- rural household reception enhancement
- Oil & Gas communication systems
Frequency Band
This antenna operates in the 617 - 4200 MHz band.
Wi-Fi Standards
Wi-Fi 3 (802.11g)| Wi-Fi 4 (802.11n)| Wi-Fi 5 (802.11ac)| Wi-Fi 6 (802.11ax)| Wi-Fi 6E (802.11ax)
