Poynting XPOL-1-5G | X-Polarised, Omni-Directional, 2X2 LTE MIMO Antenna
Poynting XPOL-1-5G | X-Polarised, Omni-Directional, 2X2 LTE MIMO Antenna - Poynting Antennas is backordered and will ship as soon as it is back in stock.
Click here to inquire about pricing or to become an authorized reseller of this product.
The XPOL-1-5G is Poynting’s second-generation “V2” version of its popular Cross Polarised (XPOL) 2x2 MIMO antenna, now with an available 4x4 MIMO variant for user-specific needs. The antenna has been completely redesigned with a new enclosure and improved antenna technology, enhancing performance across multiple frequency bands.
Expanded Frequency Coverage: Now includes the 3400 – 3800 MHz and 617 MHz bands, in addition to 617 – 960 MHz, 1700 – 2170 MHz, and 2300 – 2700 MHz. Optimised Omni-Directional Radiation Patterns: Ensures consistent coverage in urban, rural, agricultural, and commercial areas.
Peak Gain of 4 dBi: Delivers strong signal reception across all supported frequency bands. 2x2 and 4x4 MIMO Options: Available in 2x2 MIMO configuration, with a 4x4 MIMO derivative for enhanced data throughput.
Robust & Weather-Resistant Design: IP65-rated enclosure protects against dust, water, and vandalism, making it suitable for harsh environments. The XPOL-1-5G is a versatile, high-performance antenna designed to improve connectivity for 2G, 3G, 4G, and 5G applications, ensuring reliable and efficient network performance across various industries.
Key Features
- Exceptional performance over the main 4G/5G bands
- High gain for the antenna size
- Wideband 2x2 or 4x4 MIMO 4G/5G antenna
- Backwards compatible 2G/3G/4G/LTE/5G antenna
- Weather, dust and vandal resistant enclosure (IP 65)
Ideal Applications
- Outdoor antenna for Fixed Wireless Access (FWA)
- Consumer LTE/5G internet connectivity
- Industrial & Commercial LTE/5G deployments
- Urban household reception enhancement
- Power
- Energy & Water telemetry access
- Oil & Gas communication systems
- Municipal & Government systems
- Repeaters & coverage enhancement amplifiers
Frequency Band
This antenna operates in the 617 - 3800 MHz band.
Wi-Fi Standards
Wi-Fi 3 (802.11g)
