SPECIFICATIONS |
Digi TransPort WR11 XT |
Cellular |
LTE EMEA (M3) |
LTE CAT 1: 800(B20)/900(B8)/1800(B3)/2100(B1)/2600 (B7)
2G EDGE: 900/1800 MHz
Transfer rate (max): 10 Mbps down, 5 Mbps up |
LTE - EMEA/APAC (L7) |
LTE CAT 3: 800(B20)/1800(B3)/2600(B7)
3G HSPA+: 900/2100 MHz
2G Edge/GPRS: 850/900/1800/1900 MHz
Transfer rate (max): 100 Mbps down, 50 Mbps up
Approvals: Vodafone |
LTE UNITED STATES (M4) |
LTE CAT 1: 700(B12)/850(B5,B26)/AWS(B4)/1900(B2,B25)
Transfer rate (max): 10 Mbps down, 5 Mbps up
Approvals: Sprint (pending) |
LTE NORTH AMERICA (M6) |
LTE CAT 1: 700(B12,B13)/850(B5)/AWS(B4)/1900(B2)
HSPA+: 850/1900 MHz
Transfer rate (max): 10 Mbps down, 5 Mbps up
Approvals: PTCRB, AT&T, Verizon, Telus (pending) |
LTE ANZ/LATAM (M9) |
LTE CAT 1: 700(B28)/850(B5)/900(B8)/1800(B3)/2100(B1)
3G HSPA+: 850/900/2100 MHz
Transfer rate (max): 10 Mbps down, 5 Mbps up |
Global HSPA+ - (U9) |
3G HSPA+: 850/900/1700AWS/1900/2100 MHz
2G EDGE/GPRS: 850/900/1800/1900 MHz
Transfer rate (max): 21 Mbps down, 5.76 Mbps up
Approvals: PTCRB, Vodafone |
SIM SLOTS |
(2) Mini-SIM (2FF) |
SIM SECURITY |
Screw-down SIM cover |
Software & MANAGEMENT |
REMOTE MANAGEMENT |
Digi Remote Manager (cloud based); SNMP v1/v2c/v3 (user
installed/managed) |
LOCAL MANAGEMENT |
WebUI (HTTP/HTTPS); CLI (Telnet, SSH, SMS) |
MANAGEMENT/
TROUBLESHOOTING TOOLS |
FTP, SFTP, SCP; Protocol analyzer with PCAP for Wireshark;
Event logging with Syslog and SMTP; NTP/SNTP |
MEMORY |
20 MB RAM, 10 MB file space |
Ethernet |
PORTS |
(1) RJ-45; 10/100 Mbps (auto-sensing) |
PHYSICAL |
DIMENSIONS (L X W X H) |
3 in x 4 in x 1 in (7.62 cm x 10.16 cm x 2.54 cm) |
WEIGHT |
0.5 lb (.22 kg) |
STATUS LEDS |
Power on, WWAN signal strength, WWAN service |
ENCLOSURE |
Industrial (Metal) / IP30 |
Power REQUIREMENTS |
Power INPUT |
5 VDC, 15W minimum power source required |
Power Supply |
Must be used with a Digi approved power Supply |
Power CONSUMPTION |
3.5W typical (Idle); 10W typical (Peak Tx/Rx) |
ENVIRONMENTAL |
RELATIVE Humidity |
5% to 95% (non-condensing) |
APPROVALS |
Cellular |
PTCRB |
SAFETY |
UL 60950, CSA 22.2 No. 60950, EN60950 |
EMISSIONS/IMMUNITY |
CE, FCC Part 15 Class B, AS/NZS CISPR 22, EN55024, EN55022
Class B |
Warranty |
PRODUCT Warranty |
3 Years + Digi Foundations* |
*Digi Foundations can extend the standard three-Year warranty to
a Limited Lifetime Warranty that provides replacement with a new or
similar Digi product for a period of five Years from the data of
purchase. After five Years from the purchase date, the warranty
value will revert to a 40 percent credit towards the MSRP of an
equivalent product from Digi.
Enterprise Software |
DESCRIPTION |
PROTOCOL Support |
HTTP, HTTPS, FTP, SFTP, SSL, SMTP, SNMP (v1/v2c/v3), SSH,
Telnet and CLI for web management;remote management via Digi Remote
Manager; SMS management, protocol analyzer, ability to capture PCAP
for use with Wireshark;DynDNS; Dynamic DNS client compatible with
BIND9/No-IP/DynDNS |
SECURITY/VPN |
IP filtering, stateful inspection firewall with scripting,
address and port translation; VPN: IPSec with IKEv1, IKEv2, NAT
Traversal; SSL, SSLv2, SSLv3, FIPS 197, open VPN client and server;
PPTP, L2TP; (5) VPN tunnels (not upgradable); Cryptology: SHA-1,
MD5, RSA; Encryption: DES, 3DES and AES up to 256-bit (CBC mode for
IPsec); Authentication: RADIUS, TACACS+, SCEP for X.509;
certificates; Content filtering (via 3rd party); MAC address
filtering; VLAN support |
ROUTING/FAILOVER |
IP pass-through; NAT, NAPT with IP port forwarding; Ethernet
bridging; GRE; Multicast routing; Routing protocols: PPP, PPPoE,
RIP (v1, v2) OSPF, SRI, BGP, iGMP routing (multicast); IP failover:
VRRP, VRRP+TM; Automatic failover/ failback to second GSM
network/standby APN |
OTHER PROTOCOLS |
DHCP; Dynamic DNS client compatible with BIND9/No-IP/DynDNS;
QoS via TOS/DSCP/WRED |
|
